手板模型在工廠中被廣泛使用，開模前可以根據產品的圖片或結構圖，使用手板模型進行驗證，避免造成損失。從制作到后期量產有幾個階段，每個階段都缺一不可。下面就來了解一下從濟南手板制作到后期量產的步驟。

Handboard models are widely used in factories, and can be verified based on product images or structural diagrams before mold opening to avoid losses. There are several stages from production to mass production, and each stage is indispensable. Let's take a look at the steps from Jinan hand board production to later mass production.

在開發和設計新產品時，設計師需要會先定位市場。根據公司的發展規劃，結合市場定位，選擇適合自己的新產品。確定新產品方案后，使用各種操作軟件設計出所需的圖紙，圖紙可以多種格式保存，利于多方位參考在后期產品的樣機打樣中。

When developing and designing new products, designers need to first position themselves in the market. Based on the company's development plan and market positioning, choose a suitable new product for oneself. After determining the new product plan, use various operating software to design the required drawings. The drawings can be saved in multiple formats, which is conducive to multi-directional reference in the later product prototype proofing.

設計好新產品的圖紙后，就是進行手板制作，以檢驗設計的可行性。手板的制作過程分為四個過程，準備工作、設計階段、加工階段和后處理階段。這里的每個階段都是環環相扣的，只要一個階段沒有做好，就會影響到下一階段。

After designing the drawings for the new product, it is time to make a prototype to verify the feasibility of the design. The production process of a hand board is divided into four stages: preparation, design, processing, and post-processing. Each stage here is interconnected, and if one stage is not done well, it will affect the next stage.

部分零件在成型時有特殊要求，還需要使用溫流道、氣輔成型、氮氣瓶等技術。一般大型沖壓手板模型，需要考慮機床是否有下料布置，甚是否有潤滑油、多工位級進等，除了沖壓噸位外，還需要考慮沖壓次，送料設備，機床和原型模型保護設備。

Some parts have special requirements during molding and require the use of technologies such as warm runner, gas assisted molding, and nitrogen bottles. For general large-scale stamping hand board models, it is necessary to consider whether the machine tool has a cutting arrangement, and even whether there is lubricating oil, multi-station progressive, etc. In addition to the stamping tonnage, it is also necessary to consider the stamping frequency, feeding equipment, machine tool, and prototype model protection equipment.

手板制作步驟結束后，設計師將對手板進行測試。如果測試結果不理想，設計師需要結合數據對圖紙進行修改，然后重新驗證。如果外觀和性能沒有問題，就會進入下一步，小批量生產。

After the steps of making the hand board are completed, the designer will test the hand board. If the test results are not satisfactory, the designer needs to modify the drawings based on the data and then revalidate them. If there are no issues with appearance and performance, we will proceed to the next step, small-scale production.

小批量生產的目的是看新產品有沒有新的缺點。如果沒有新的缺陷，就可以準備模具了。開模后就可以正式生產了，正式生產后產品才能投放市場，企業才能開始正式盈利。更多相關事項就來我們網站http://www.tescen.com咨詢了解！

The purpose of small-scale production is to see if new products have new shortcomings. If there are no new defects, the mold can be prepared. After the mold is opened, it can be officially produced. Only after formal production can the product be put on the market and the enterprise begin to make profits. For more related matters, come to our website http://www.tescen.com Consultation and understanding!
